HOWO TX 8x4 12m³ Concrete Mixer Truck Construction Mixer Concrete Mixer Truck for Sale Concrete Mixi

Why Choose Our Products?

  • - Certificate: ASME, ISO, BV, SGS, CCC etc.
  • - More than 30 independents workshops for different trucks.
  • - 1000 sets of equipment, 25 assemble lines.
  • - 8000 staffs including 300 senior engineers and technicians.
  • - 800 kinds of trucks and semi-trailers covering different industry.
  • - 20 years wholesale experience.
  • - Export to 90 countries.
  • We are 100% Straight Factory Manufacturer.
    We have 100% Quality Assurance.
    Welcome to visit our factory!

    Vehicle Parameters
    Vehicle Model
    EHY5310GJBZ
    Vehicle Brand

    Overall dimensions
    10350×2500×3998mm
    Curb weight
    14500kg
    Loading capacity
    14m3
    Color
    optional
    Chassis Parameters
    Chassis model
    ZZ1317N306GE1
    Chassis brand
    SINOTRUK HOMAN
    Overall dimensions
    8955×2496×3035mm
    Wheel base
    1800+3050+1350mm
    Front/rear wheel track
    2020/2020/1860/1860mm
    Front/rear suspension
    1460/1250mm
    Approach/departure angle
    18.5/41°
    Maximum speed
    85km/h
    Cab
    Configuration
    HOWO T5G cab, ABS, air conditioner
    Color
    White, other color is optional
    Engine
    Model
    MC07.34-50
    Emission
    Euro 5
    Type
    6 cylinders, in-line, 4-stroke, water-cooled, turbo inter-cooling, direct injection, exhaust valve brake,diesel engine
    Rated power
    340hp,rated power speed 2300rpm
    Displacement
    6870ml
    Max.torque
    1250N.m
    Bore x stroke
    108x125mm
    Manufacturer
    China National Heavy Duty Truck Group Co.,Ltd
    Tire
    11.00R20 steel wire tire
    12+1 nos
    Transmission
    HW13710L, 10 speed forward 2 reverse
    Steering device
    Power assisted steering ZF8198
    Steering wheel
    Left hand drive
    Concrete Mixer Structure  Parameters
    Mixing capacity(m³)
    14
    Color and Logo
    Optional
    Feeding speed (m³/min)
    ≥5
    Discharge speed(m³/min)
    ≥3
    Discharge residual rate
    ≤0.5%
    Slump scope(mm)
    50-210
    Water tank capacity(L)
    300
    Water pressure(Mpa)
    0.35-0.38
    Tank material
    6mm alloy steel
    Tank front head
    8mm alloy steel
    Reducer
    Italy Bonfiglioli
    Hydraulic motor
    Germany REXROTH
    Hydraulic pump
    Germany REXROTH
    Radiator
    KAIPENG
    Standard Configuration
    chassis,sub frame,mixer tank,reducer, hydraulic pump,hydraulic motor, radiator,water tank,cleaning hose,feed port, discharge port,climbing ladder,air pressure water supply device.
    Italy Bonfiglioli reducer,Germany REXROTH hydraulic pump,Germany REXROTH hydraulic motor,KAIPENG radiator,mixer tank(main tank 6mm alloy steel wear resistant material,front tank head 8mm alloy steel wear resistant material)


    Car Purchase Guidelines

    FAQ

    Q1:Could your company manufacture products based on my requests?
    A:Yes. With our R&D team, Chengli is specialized in engineering and making specialized vehicles. We can provide any products according to your demands, like the volume, painting, size, logo, the engine, and even the chassis.

    Q2:What's your quality guanrantee?
    A:We are a government-certified enterprise recognized by China's Ministry of Industry and Information Technology (MIIT), we have passed the ISO, CCC, SGS. We also hold export qualifications.

    Q3. What are your main products?
    A: Fire and emergency response vehicles, tanker trucks, refrigerated trucks, sanitation trucks, garbage truck, sprinkler truck, boom truck, wrecker trucks and so on. The annual production capacity is exceeding 8,000 units.

    Q4. Are you a factory or trading company?
    A: Chengli a the original factory, not a middleman or agent.

    Q5. What are your terms of payment? What is your terms of delivery?
    A: Generally speaking, 30% T/T deposit in advance. Terms are EXW, FOB, CFR, CIF.

    Q6. How about your delivery time?
    A: 10 to 25 days after receiving your advance payment. It also depends on the items and the quantity.

    Q7. What is the price of your product?
    A: We are the direct factory, so the price can be competitive. Visit our company and let us enjoy a tea to further talk about the price!

    Q8. Do you test all your goods before delivery?
    A: Yes, we have 100% test before delivery.

    Q9.What is the warranty period for your products?
    A:The warranty period of export vehicles can be 12 months, based on the order.

    Q10.Do your special vehicles comply with national/regional safety standards and emission regulations?
    A:Yes.

    Q11.What after-sales services do you provide?
    A:We provide comprehensive after-sales services, including free parts, maintenance, repairs, technical support, and on-line tech support.

    Q12:Can you make OEM or ODM?
    A:Yes, we welcome the importer and wholesaler from worldwide for OEM and ODM business.

    Q13:Where is your factory located? How can I visit there?
    A:The address is at the intersection of Xingguang Road 1 and National Highway 316 in Zengdu Economic and Technological Development Zone, Suizhou City, Hubei Province, China. We will pick you up at Wuhan Airport.
