[Overall Technical Parameters ] | ||
Product Name | Dump Truck Mining Tipper Truck | |
Overall Dimensions(mm) | 5790*2020*2680 | |
Curb weight(Kg) | 6700 | |
Loading Capacity(Kg) | 5200 | |
Total Mass(Kg) | 11900 | |
Cargo Tank Dimension(mm) | 3800*2200*1200 | |
Cargo Tank Volume(m³) | 8 | |
Tank Body Material | Carbon Steel | |
Cargo Tank thickness(mm) | Side 6 Bottom 8 | |
Cargo Tank Lifting method | Hydraulic Cylinder Lifting | |
Number of Cylinders(pcs) | 1 | |
Position of Cylinder | Girder Front/Middle | |
Cylinder Diameter(mm) | 180 | |
Door Position | Rear/Side/Top | |
[Chassis Technical Parameters] | ||
Chassis brand | Dongfeng | |
Drive Method | 4*2 | |
Driving Position | Left or Right Hand Drive | |
Steering Device | Power Assisted Steering | |
Wheelbase(mm) | 3360 | |
Engine Brand and Model | Howo Power/MC11.44-60 | |
Max engine power(Kw) | 120 | |
Engine Displacement(ml) | 6518 | |
Engine emission standard | Euro 6 | |
Number of Engine cylinders | 6 | |
Fuel Type | Diesel | |
Gearbox | 5 Speed Forward 1 Reverse | |
Front/Rear Axle(T) | 2.5/3.5 | |
Suspension | Multi leaf springs | |
Brake Systerm | Front/Rear Drum full air braking | |
Wheels and Tire Spec | 6 | |
Cab Configuration | Single row cab, air conditioning, radio, MP3 and USB port | |
Rated Voltage | 24V,DC | |
