[Vehicle technical parameters] | |||
Product trademark | Cheng Li brand | Announcement batch | 378 |
product name | refuelling truck | ||
Total mass (kg) | 7360 | Tank volume (m3) | 4.15 |
Rated mass (kg) | 3450 | outline dimension (mm) | 5990 * 2050 * 2500 (mm) |
curb weight (kg) | 3780 | Goods Chamber Size (mm) | |
Number of passengers (person) | 2 | Maximum load mass of the saddle (kg) | |
Approach angle / departure angle of (°) | 27.7/15 | Front suspension / rear suspension (mm) | 1055/1627 |
axle weight (kg) | 2640/4720 | Top vehicle speed (km/h) | 80 |
[Chassis technical parameters] | |||
Chassis model | EQ1075SJ3CDFWXP | Chassis name | truck chassis |
brand name | Dongfeng | manufacturing enterprise | Dongfeng |
number of axles | 2 | Number of tires | 6 |
wheel base (mm) | 2700,2950,3308 | ||
tyre size | 7.00R16,7.00R16LT 14PR | ||
Number of steel plate spring sheets | 6/6+5,3/3+3,2/3+2,5/7+3,3/6+5,3/3+2,2/2,3/8+6 | front gauge (mm) | 1525,1519,1605 |
Fuel types | diesel oil | rear track (mm) | 1498,1516,1586,1670,1458,1650,1630 |
Emission basis standard | Euro 4 5 6 | ||
engine type | Engine production enterprise | engine displacement | engine power |
Q23-115E60 | Quanchai | 2300 | 85 |
D20TCIF1 | Yunnei | 1999 | 93 |
Q23-132E60 | Quanchai | 2300 | 97 |
The vehicle is detailed | |||
Chassis instructions | Chassis configuration:3308 wheelbase dangerous goods new regulation chassis, 1730 new cab, D20TCIF1 (126 hp) engine, efficient4-valve engine, Wanliyang 5-gear transmission, 188 double-deck through train frame, 1.8/3.5T front and rear axle, 7.00R16 vacuum tire. New regulations: explosion-proof tire device, lane departure warning, anti-collision warning, safety belt warning, LCDinstrument, original factory air conditioning, central control lock, electric window, broken air brake, cruise at fixed speed | ||
