Vehicle model | CLW5060XLJ6 | Overall dimensions | 5995×2490×3150 (mm) |
Curb weight | 4200 kg | Chassis model | ZZ1047F341CE145 |
GVW | 4498 kg | Wheel base | 3360 mm |
Fuel tank volume | 120 L | Tire specification | 7.50R16 |
Rated passenger | 4-6 persons | Number of tires | 6 + 1 spare |
Engine parameters | |||
Engine model | ISF3.8S3141 | Displacement | 2800 ml |
Engine power | 108kw | Horsepower | 148HP |
Max speed | 100km/h | Number of cylinders | 4 |
Emission standard | EURO III | Transmission | Manual |
Fuel | Diesel | Gear box | 5MT |
System | Device Name |
Video and audio system | GPS tracking. (Per need) |
32 inch X1aomi TV under the front bed (flip board on the top) | |
Power amplifier + sound system | |
Electrical system | 3KW sine wave charging inverter integrated machine |
24V/300Ah lithium battery and low voltage protector | |
Dual battery isolator, 32A leakage protector | |
Hidden warm color car interior LED lighting/reading light/top starry sky light | |
Black acrylic switch panel | |
Circuit and electrical control system 220V inverter socket, USB charging port | |
External 220V mains interface/15m mains external plug-in line | |
4 way monitoring cameras per need | |
600W solar panel on the roof | |
A TV antenna that receives TV channels. | |
Waterway system | 280L stainless steel antifreeze water purification tank |
100L stainless steel antifreeze sewage tank | |
Vehicle intake and drainage system assembly | |
Gravity water inlet | |
Circular stainless steel vegetable washing basin (including faucet) | |
15 meters external water pipe | |
Mechanical blowdown valve | |
Fuel heater (heating, hot water) | |
Diaphragm water pump (DC12V) |
