【Vehicle Technical Parameters】 | ||
Product Name | Wrecker Towing Truck | |
Curb Weight(Kg) | 4200 | |
Boundary Dimension(mm) | 5995×2300×2350 | |
Slab Length(mm) | 5400 | |
Plate Width(mm) | 2300 | |
Plate Bearing Weight(t) | 3 | |
The Rear Bracket Arm Carries The Weight(t) | 2.5 | |
Winch Pull(t) | 4 | |
Total Length of Wire Rope(m) | 20 | |
Auxiliary Wheel | A Pair | |
Operating Ambient Temperature(°C) | -20~45 | |
Max Passengers Allowed | 3 | |
【Chassis Technical Parameters】 | ||
Chassis Name | JAC | |
Brake | Automatically Air-Cut Brake | |
Type of Fuel | Diesel Oil | |
Engine Power(KW) | Quan Chai 112 | |
Front Axle/Rear Axle(t) | 2/3.5 | |
Gearbox | 5 Speed Manual Transmission | |
Number of Axes | 2 | |
Wheelbase (mm) | 3365 | |
Number of Tires | 6 | |
Tire Spec. | 7.00R16 | |
