【Vehicle Technical Parameters】 | ||
Product Name | Wrecker Towing Truck | |
Curb Weight(Kg) | 11300 | |
Boundary Dimension(mm) | 10550×2550×2875 | |
Slab Length(mm) | 8300 | |
Plate Width(mm) | 2550 | |
Plate Bearing Weight(t) | 10 | |
The Rear Bracket Arm Carries The Weight(t) | 10 | |
Winch Pull(t) | 10 | |
Total Length of Wire Rope(m) | 30 | |
Auxiliary Wheel | A Pair | |
Operating Ambient Temperature(°C) | -20~45 | |
Max Passengers Allowed | 3 | |
【Chassis Technical Parameters】 | ||
Chassis Name | SINOTRUK | |
Brake | Automatically Air-Cut Brake | |
Type of Fuel | Diesel Oil | |
Engine Power(KW) | SINOTRUK 180 | |
Front Axle/Rear Axle(t) | 5/10 | |
Gearbox | 9 Speed Manual Transmission | |
Number of Axes | 2 | |
Wheelbase (mm) | 5600 | |
Number of Tires | 6 | |
Tire Spec. | 10.00R20 | |
