Chassis model

EQ1185LJ9CDE

Wheelbase

4500mm

engine model

D4.0NS6B195

Engine power

Cummins 195 HP

Dimensions

7160/4500/1260/1400

curb weight

7100,7400

Maximum total mass

18000kg

Rated contained mass

10770,10705,10470,10405

Operation method

Electronic control/manual

Chassis configuration: Cummins 195 horsepower, Fast  8-speed gearbox, 2315 cab, 4.5T front axle, 10T rear axle, 10.00 tubeless tires,  250 beam, air brake, air conditioning, electric doors and windows, central  locking.

Upper body configuration: Made of high-quality  high-strength carbon steel plates, the hook arm system is a telescopic arm  with hydraulic outriggers, manual and autonomous operation, and remote  control operation. The pulling arm force is not less than 15 tons, and the  rear outriggers are 8cm above the ground.

[Body configuration]

Control System

Remote control + manual operation, fast and safe,  proprietary technology, industry leading

Hydraulic system

The cylinders, pumps and valves are specially  designed by our company and produced by well-known domestic factories. They  are reasonably matched and cost-effective; imported seals are used in key  parts, with stable performance and reliable quality.

safety protection

(1) The main cylinder is specially equipped with a  built-in two-way unloading valve, which effectively reduces the system  pressure at the end of the stroke and protects the entire hydraulic system  and the pull arm for durability.

(2) The lifting system is equipped with a balancing  device, which can move at a constant speed regardless of no-load or heavy  load, to avoid damage to vehicles or equipment caused by strong impacts;

(3) The hydraulic system and each branch oil circuit  are equipped with two-way overload protection, and the rated pressure is  adjusted according to the actual working conditions of each moving part to  effectively avoid abnormal vehicle damage caused by system overload or  improper use;

(4) The hydraulic  system is equipped with an oil line explosion-proof locking device to prevent  potential safety hazards due to oil pipe bursts and ensure the safety of  personnel and vehicles;

(5) The upper part  of the pulling arm is equipped with a reinforced hydraulic box locking  device, which can be used correctly to ensure transportation safety.

interlock protection

Each action is associated with interlocking  protection to prevent hydraulic or mechanical failures caused by  misoperation, eliminate potential safety hazards, and extend the service life  of the vehicle.

Pull arm structure

The tensioning arm structural parts are made of  high-strength steel, with special partial treatment, which has strong bearing  capacity and is not easy to deform.

arm tops

The upper arm tops  have been polished and rust-removed, and painted through multiple processes  to ensure that the appearance and color meet the requirements; the upper arm  top assemblies have undergone special bench tests and heavy-duty load tests  to ensure quality.
