1.lpg truck: Liquid Petroleum Gas, Propane, Butane, Liquid Ammonia, etc.
2.Available tank sizes of LPG storage tank: 5m³~200m³, 2.5ton~100tons.
3.Tank Design Standard : GB-150, ASME VIII Division I U STAMP, CCC, ISO9001 : 2008.
4.Tank Testing: 100% Radiaographic Test, Magnetic Power Test, Water Pressure.
5. Optional for lpg gas plant equipments: LPG pump and motor, LPG compressor, volume flow meter, filling scales and lpg dispenser,ball valves,check valves,non-return valves,glass valve,strainer,by-pass valve and so on.
| ITEM | PARAMETER |
| Chassis Technical Parameters | |
| Driving mode | 4X2 |
| Overall dimension | 6800*2500*3250mm |
| Gross weight | 11,000kg |
| Wheelbase | 3360mm |
| Cabin | ISUZU KV100 cabin; With A/C, power steering |
| Engine - Brand | 4KH1CN6LB |
| Engine - Horsepower | 120hp |
| Engine - Emission standard | Euro 2-3-4-5-6 |
| Gear box | ISUZU, 5 forward gears and 1 reverse |
| Tyre | 7.00R16 (6pcs with 1 spare) |
| Front axle loading | 2,500kg |
| Rear axle loading | 4,800kg |
| Tank body parameters | |
| LPG tank volume | 5,000 liters, 5CBM |
| Tank material | Q345R |
| Tank thickness | 10mm |
| End plate | 10mm |
| Tank length | As designed |
| Gas phase | DN25 or DN50 or customized |
| Liquid phase | DN 50 or DN80 or customized |
| Filling gas | Propane (LPG) |
| Design pressure | 1.61Mpa |
| Hydraulic temperature | 2.21Mpa |
| Working temperature | -20~50℃ |
| Design code | GB150.1~2011 |
| Accessories | |
| Level gauge | Float ball type at the rear of tank |
| Safety valve | DN80*1 |
| Tool and valve box | Equipped |
| Radiator of hydraulic oil | Equipped |
| LPG pump | CORKEN Z2000, driven by truck engine through PTO |
| Dispenser machine | Single nozzle with English remarks |
| Filling hose | 15 meters |
| Pressure gauge | One set |
| thermometer | One set |
| Emergency valve | Controlled valve box and installed at the rear of truck |
| Fender | Steel material |
| Fire extinguisher holder | Installed at left and right sides of rear truck *2 |
| Exhaust shaft | At the front of truck cabin for safety |
Key Features & Superior Advantages
--All-in-One Mobile Refueling System
Equipped with a 5-cubic-meter LPG tank, a high-performance domestic pump, and an accurate flow meter, thistruck enables efficient tank refilling and direct vehicle refueling. The system is installed at the rear for easy access,allowing quick connections and operations in various field conditions.
--Optimized Chassis & Driving Comfort
The Isuzu KV100 chassis provides a stable platform with a 2.5-ton front axle and 4.8-ton rear axle, ensuring durabilityunder load. The cab is designed for operator comfort and convenience, featuring air conditioning, power steering.central locking, electric windows, and a tiltable cab. Safety is enhanced with ABS and air-assisted brakes, while the7.00R16 tires ensure reliable traction.
--Compact & Highly Maneuverable Design
With its compact dimensions and 3360 mm wheelbase, this LPG refueling truck can easily navigate urban areas,industrial sites, and confined job sites where traditional refueling stations are unavailable. It's your "gas station onwheels.'
--Compliance with Safety & Quality Standards
As an LPG transport and refueling unit, the vehicle adheres to stringent safety regulations for pressure vessels-2. Keysafety components include reliable valves and pressure management systems, ensuring secure storage, transport anddispensing of LPG
